Environmentally friendly storage cranes optimise terminal operations at CTB

HHLA Executive Board member Jens Hansen: “By using new technologies, we want to fully electrify the container handling process at CTB, our largest terminal in Hamburg, while significantly improving our energy efficiency. Using electricity from renewable sources will allow us to continue decarbonising our workflows at the port. We previously demonstrated how this can work at the neighbouring Container Terminal Altenwerder. The switch to environmentally friendly storage crane systems will bring us a big step closer to this goal.”

Dr. Melanie Leonhard, Senator for Economic Affairs: “Burchardkai is Hamburg's largest and oldest container terminal. This is where the container era began for the Port of Hamburg. The image of large vessels being unloaded at the container gantry cranes characterises our port. Burchardkai represents the global exchange of goods and the internationally connected global economy like no other place in Hamburg. With the commissioning of the modern storage crane systems, the terminal will become even more energy efficient and thus further optimised. New technologies make a decisive contribution towards creating sustainable value for our port based on innovation and quality, as formulated in the mission statement of the Port of Hamburg’s development plan.”

Jens Kerstan, Minister for Environment, Climate, Energy and Agriculture: “Climate protection begins locally. With the start-up of the fourth automated storage crane system, we have achieved a milestone on our path towards decarbonising Container Terminal Burchardkai. This project will save almost five and a half million litres of diesel and 11,000 tonnes of CO₂ every year. And there’s more: electrified storage cranes are not only significantly quieter; they allow a considerable amount of soot, particulate matter and nitrogen to be avoided. This directly improves the quality of life of Hamburg’s residents, especially in areas close to the port. The ten million euros from the European Regional Development Fund were optimally invested here. The project gives considerable momentum to the modernisation of container handling, makes a long-term contribution to climate protection and demonstrates impressively that increased capacities can be achieved with lower emissions. In Hamburg, we want to live and do business in a carbon-neutral manner by 2045. It is essential that everyone in politics, the scientific community, business and the general public pull together with all our strength. Projects with charisma, such as this one, are particularly motivating.”

The four new storage blocks, which were gradually put into operation over the first half of 2023, complement the electric container storage at CTB by an additional 8,500 standard containers (TEU). All in all, the automated container yard at CTB thus has a capacity of almost 39,000 TEU spread across a total of 19 storage blocks. The gradual switch of the energy-intensive process of moving goods in and out of storage using diesel-powered straddle carriers in favour of electric storage crane systems will lead to the further reduction of carbon and harmful emissions at the terminal.

The automated storage crane systems that store and prepare containers for onward transport run on green electricity. The switch also creates the conditions for the conversion of horizontal transport to fully automated container transport (Automated Guided Vehicles), which are battery-operated and thus also climate-neutral.

The CTB has been further developed on an ongoing basis during operations since 2006. The storage blocks with state-of-the-art storage crane systems have been fully automated at the terminal since 2010. With the commissioning of the four additional blocks, the terminal's efficient use of space has increased by more than 30 percent. Due to the fact that the port is so close to the city, it is very important to use the space efficiently and to keep the emissions generated at the Port of Hamburg as low as possible. This includes noise and light emissions. Three additional storage blocks are currently being built at CTB, which will expand storage capacity to a total of 22 blocks starting in 2024. In this way, HHLA continues to drive its "balanced logistics" sustainability strategy consistently forward and is one step closer to its goal of achieving climate-neutral production across the entire Group by 2040.

The automated container storage at CTB consists of storage blocks that are each 42 metres wide and 375 metres long and arranged side by side, with a capacity between 1,980 and 2,130 TEU depending on their type. CTB stands out because its storage crane system consists of three portal cranes that can drive over each other. This is globally unique and increases productivity: crane operation is optimised and the cranes’ traversability results in a more efficient path through the aisles (roadway diagram). Depending on requirements, one side of the block storage can also be used more intensively. The storage crane system’s high-performance IT system is integrated into the terminal’s overall control system and has been supported by a specially developed AI module for several years. This helps it find optimal storage locations for the stored steel boxes, which can reduce the energy-consuming restacking of containers.
